ATPB Monoclonal antibody

ATPB Monoclonal Antibody for IF, IHC, WB, ELISA

Host / Isotype

Mouse / IgG2b

Reactivity

Human, Mouse , Rat and More (1)

Applications

WB, IHC, IF, ELISA

Conjugate

Unconjugated

CloneNo.

1A11B9

Cat no : 66600-1-Ig

Synonyms

ATP5B, ATPB, ATPMB, ATPSB, Cell and organelle markers, Mitochondria Marker, Mitochondrial Marker, Mitochondrion Marker

Validation Data Gallery

Filter:
  • Western Blot (WB) analysis of various lysates using ATPB Monoclonal antibody (66600-1-Ig)

    WB analysis using 66600-1-Ig

    Various lysates were subjected to SDS PAGE followed by western blot with 66600-1-Ig (ATPB antibody) at dilution of 1:10000 incubated at room temperature for 1.5 hours.

  • Immunohistochemistry (IHC) staining of human liver tissue using ATPB Monoclonal antibody (66600-1-Ig)

    IHC staining of human liver using 66600-1-Ig

    Immunohistochemical analysis of paraffin-embedded human liver tissue slide using 66600-1-Ig (ATPB antibody) at dilution of 1:500 (under 40x lens).

  • Immunohistochemistry (IHC) staining of human liver tissue using ATPB Monoclonal antibody (66600-1-Ig)

    IHC staining of human liver using 66600-1-Ig

    Immunohistochemical analysis of paraffin-embedded human liver tissue slide using 66600-1-Ig (ATPB antibody) at dilution of 1:500 (under 10x lens).

  • Immunohistochemistry (IHC) staining of mouse skeletal muscle tissue using ATPB Monoclonal antibody (66600-1-Ig)

    IHC staining of mouse skeletal muscle using 66600-1-Ig

    Immunohistochemical analysis of paraffin-embedded mouse skeletal muscle tissue slide using 66600-1-Ig (ATPB antibody) at dilution of 1:500 (under 10x lens. Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

  • Immunohistochemistry (IHC) staining of mouse skeletal muscle tissue using ATPB Monoclonal antibody (66600-1-Ig)

    IHC staining of mouse skeletal muscle using 66600-1-Ig

    Immunohistochemical analysis of paraffin-embedded mouse skeletal muscle tissue slide using 66600-1-Ig (ATPB antibody) at dilution of 1:500 (under 40x lens. Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

  • Immunofluorescence (IF) / fluorescent staining of HepG2 cells using ATPB Monoclonal antibody (66600-1-Ig)

    IF Staining of HepG2 using 66600-1-Ig

    Immunofluorescent analysis of (4% PFA) fixed HepG2 cells using ATPB antibody (66600-1-Ig, Clone: 1A11B9 ) at dilution of 1:200 and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L).

Tested Applications

Positive WB detected inHeLa cells, HEK-293 cells, HepG2 cells, Jurkat cells, HSCT6 cells, Raw 264.7 cells, NIH/3T3 cells
Positive IHC detected inhuman liver tissue, mouse skeletal muscle tissue
Note: suggested antigen retrieval with TE buffer pH 9.0; (*) Alternatively, antigen retrieval may be performed with citrate buffer pH 6.0
Positive IF detected inHepG2 cells

Recommended dilution

ApplicationDilution
Western Blot (WB)WB : 1:5000-1:50000
Immunohistochemistry (IHC)IHC : 1:250-1:1000
Immunofluorescence (IF)IF : 1:50-1:500
It is recommended that this reagent should be titrated in each testing system to obtain optimal results.
Sample-dependent, Check data in validation data gallery.

Published Applications

WBSee 1 publications below

Product Information

66600-1-Ig targets ATPB in WB, IHC, IF, ELISA applications and shows reactivity with Human, Mouse , Rat samples.

Tested Reactivity Human, Mouse , Rat
Cited Reactivityrat
Host / Isotype Mouse / IgG2b
Class Monoclonal
Type Antibody
Immunogen ATPB fusion protein Ag11177
Full Name ATP synthase, H+ transporting, mitochondrial F1 complex, beta polypeptide
Calculated Molecular Weight 529 aa, 57 kDa
Observed Molecular Weight45-57 kDa
GenBank Accession NumberBC016512
Gene Symbol ATP5B
Gene ID (NCBI) 506
RRIDAB_2881960
Conjugate Unconjugated
Form Liquid
Purification MethodProtein A purification
Storage Buffer PBS with 0.02% sodium azide and 50% glycerol pH 7.3.
Storage ConditionsStore at -20°C. Stable for one year after shipment. Aliquoting is unnecessary for -20oC storage. 20ul sizes contain 0.1% BSA.

Background Information

ATP5B, also named as ATPMB and ATPSB, belongs to the ATPase alpha/beta chains family. It is a high affinity HDL receptor for apolipoprotein A1. ATP5B is a subunit of mitochondrial ATP synthase (F1F0 ATP synthase or Complex V ). ATP5B has a calculated molecular mass of 57 kDa and ~5 kDa transit peptide can be removed in the mature form.

Protocols

Product Specific Protocols
WB protocol for ATPB antibody 66600-1-IgDownload protocol
IHC protocol for ATPB antibody 66600-1-IgDownload protocol
IF protocol for ATPB antibody 66600-1-IgDownload protocol
Standard Protocols
Click here to view our Standard Protocols

Publications

SpeciesApplicationTitle
ratWB

Cell Biol Int

The effect of all-trans retinoic acid on the mitochondrial function and survival of cardiomyoblasts exposed to local photodamage

Authors - Simona Kurekova
View Article
