Anticorps Polyclonal de lapin anti-LAG-3/CD223

LAG-3/CD223 Polyclonal Antibody for WB, IHC, IF-P, IP, ELISA

Hôte / Isotype

Lapin / IgG

Réactivité testée

Humain, rat, souris

Applications

WB, IHC, IF-P, IP, ELISA

Conjugaison

Non conjugué

Publications(14)

Avis (2)

N° de cat : 16616-1-AP

Synonymes

CD223, LAG3, FDC, LAG 3, LAG-3

---

Galerie de données de validation

•

  WB analysis using 16616-1-AP

  Various lysates were subjected to SDS PAGE followed by western blot with 16616-1-AP (LAG-3/CD223 antibody) at dilution of 1:1000 incubated at room temperature for 1.5 hours.

•

  IP experiment of mouse liver using 16616-1-AP

  IP result of anti-LAG-3 (IP:16616-1-AP, 4ug; Detection:16616-1-AP 1:500) with mouse liver tissue lysate 4000ug.

•

  IHC staining of human tonsillitis using 16616-1-AP

  Immunohistochemical analysis of paraffin-embedded human tonsillitis tissue slide using 16616-1-AP (LAG-3/CD223 antibody) at dilution of 1:2000 (under 20x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IHC staining of human tonsillitis using 16616-1-AP

  Immunohistochemical analysis of paraffin-embedded human tonsillitis tissue slide using 16616-1-AP (LAG-3/CD223 antibody) at dilution of 1:2000 (under 20x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IF Staining of human tonsillitis using 16616-1-AP

  Immunofluorescent analysis of (4% PFA) fixed human tonsillitis tissue using LAG-3 antibody (16616-1-AP) at dilution of 1:200 and CoraLite®488-Conjugated AffiniPure Goat Anti-Rabbit IgG(H+L).

•

  IF Staining of human tonsillitis using 16616-1-AP

  Immunofluorescent analysis of (4% PFA) fixed human tonsillitis tissue using LAG-3 antibody (16616-1-AP) at dilution of 1:200 and CoraLite®488-Conjugated AffiniPure Goat Anti-Rabbit IgG(H+L).

---

Applications testées

• Résultats positifs en WB: PHA treated human PBMCs,
• Résultats positifs en IP: tissu hépatique de souris
• Résultats positifs en IHC: tissu d'amygdalite humain, ; il est suggéré de démasquer l'antigène avec un tampon de TE buffer pH 9.0; (*) À défaut, 'le démasquage de l'antigène peut être 'effectué avec un tampon citrate pH 6,0.
• Résultats positifs en IF-P: tissu d'amygdalite humain,

Dilution recommandée

• Western Blot (WB): WB : 1:500-1:2000
• Immunoprécipitation (IP): IP : 0.5-4.0 ug for 1.0-3.0 mg of total protein lysate
• Immunohistochimie (IHC): IHC : 1:1000-1:4000
• Immunofluorescence (IF)-P: IF-P : 1:50-1:500

It is recommended that this reagent should be titrated in each testing system to obtain optimal results.

Sample-dependent, check data in validation data gallery

Applications publiées

• WB: See 7 publications below
• IHC: See 6 publications below
• IF: See 3 publications below

Informations sur le produit

16616-1-AP cible LAG-3/CD223 dans les applications de WB, IHC, IF-P, IP, ELISA et montre une réactivité avec des échantillons Humain, rat, souris

• Réactivité: Humain, rat, souris
• Réactivité citée: Humain, souris
• Hôte / Isotype: Lapin / IgG
• Clonalité: Polyclonal
• Type: Anticorps
• Immunogène: LAG-3/CD223 Protéine recombinante Ag9909
• Nom complet: lymphocyte-activation gene 3
• Masse moléculaire calculée: 525 aa, 57 kDa
• Poids moléculaire observé: 60-70 kDa
• Numéro d’acquisition GenBank: BC052589
• Symbole du gène: LAG-3
• Identification du gène (NCBI): 3902
• Conjugaison: Non conjugué
• Forme: Liquide
• Méthode de purification: Purification par affinité contre l'antigène
• Tampon de stockage: PBS with 0.02% sodium azide and 50% glycerol
• Conditions de stockage: Stocker à -20°C. Stable pendant un an après l'expédition. L'aliquotage n'est pas nécessaire pour le stockage à -20^oC Les 20ul contiennent 0,1% de BSA.

Informations générales

LAG-3, also known as CD223, is an immune checkpoint molecule that regulates both T-cell activation and homeostasis. LAG-3 is expressed on activated T cells, NK cells, regulatory T cells, and plasmacytoid dendritic cells. It is a CD4-related molecule that binds MHC class II. LAG-3 plays an important role in modulating T cell expansion and function, and blockade of LAG-3 with monoclonal antibodies can augment T cell function. (PMID: 15634887; 21086108; 28783703)

Publications

Species	Application	Title
human	WB	Cancer Immunol Immunother; Novel roles of VAT1 expression in the immunosuppressive action of diffuse gliomas.; Authors - Pei Yang
human	IHC	Ann Transl Med; Single-cell RNA-seq reveals transcriptional landscape and intratumor heterogenicity in gallbladder cancer liver metastasis microenvironment.; Authors - Yigang Zhang
human	IHC	Front Oncol; The immune checkpoint expression in the tumor immune microenvironment of DLBCL: Clinicopathologic features and prognosis; Authors - Jiajia Ma
human	WB	Int J Oncol; Effect of DPP4/CD26 expression on SARS‑CoV‑2 susceptibility, immune response, adenosine (derivatives m62A and CD) regulations on patients with cancer and healthy individuals; Authors - Jiaman Du
human	WB	Br J Ophthalmol; Implications of LAG3 and CTLA4 immune checkpoints beyond PD-1/PD-L1 as a potential target in determining the prognosis of uveal melanoma patients; Authors - Seema Kashyap
human	WB	J Clin Invest; Targeting fibrinogen-like protein 1 enhances immunotherapy in hepatocellular carcinoma; Authors - Mingen Lin

Avis

The reviews below have been submitted by verified Proteintech customers who received an incentive for providing their feedback.

---

FH

Sofia (Verified Customer) (05-27-2025)

Antibody did not work as expected even using the suggested antigen retrieval. I'll try it again using a different antigen retrieval.

• Applications: Immunofluorescence
• Primary Antibody Dilution: 1:200
• Cell Tissue Type: Brain samples

FH

Eman (Verified Customer) (09-20-2021)

the antibody works very well for WB the recommended dilution is 1:500 to 1:1000 i think we can even dilute it more this antibody is higly recommended

• Applications: Western Blot
• Primary Antibody Dilution: 1:1000 overnight
• Cell Tissue Type: HEK293T cells

LAG-3/CD223 Antibody Western Blot validation (1:1000 overnight dilution) in HEK293T cells (Cat no:16616-1-AP)
