Granzyme B Polyclonal antibody

•

  WB analysis of HL-60 using 13588-1-AP

  HL-60 cells were subjected to SDS PAGE followed by western blot with 13588-1-AP (GZMB antibody) at dilution of 1:500 incubated at room temperature for 1.5 hours.

•

  IHC staining of human lymphoma using 13588-1-AP

  Immunohistochemical analysis of paraffin-embedded human lymphoma tissue slide using 13588-1-AP (GZMB antibody) at dilution of 1:200 (under 10x lens. Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IHC staining of human lymphoma using 13588-1-AP

  Immunohistochemical analysis of paraffin-embedded human lymphoma tissue slide using 13588-1-AP (GZMB antibody) at dilution of 1:200 (under 40x lens. Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IHC staining of mouse spleen using 13588-1-AP

  Immunohistochemical analysis of paraffin-embedded mouse spleen tissue slide using 13588-1-AP (Granzyme B antibody) at dilution of 1:200 (under 10x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IHC staining of mouse spleen using 13588-1-AP

  Immunohistochemical analysis of paraffin-embedded mouse spleen tissue slide using 13588-1-AP (Granzyme B antibody) at dilution of 1:200 (under 40x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IF Staining of Jurkat using 13588-1-AP

  Immunofluorescent analysis of (4% PFA) fixed Jurkat cells using Granzyme B antibody (13588-1-AP) at dilution of 1:400 and CoraLite®488-Conjugated Goat Anti-Rabbit IgG(H+L) (SA00013-2).

•

  IF Staining of MCF-7 using 13588-1-AP

  Immunofluorescent analysis of (-20°C Methanol) fixed MCF-7 cells using Granzyme B antibody (13588-1-AP) at dilution of 1:400 and CoraLite®488-Conjugated Goat Anti-Rabbit IgG(H+L) (SA00013-2).

Granzyme B Polyclonal Antibody for WB, IHC, IF/ICC, ELISA

Cat No. 13588-1-AP

Publications(52)

Host / Isotype

Rabbit / IgG

Reactivity

human, mouse and More (1)

Applications

WB, IHC, IF/ICC, ELISA

Synonyms

GZMB, Cathepsin G-like 1, CCPI, CGL 1, CGL1

---

Tested Applications

• Positive WB detected in: HL-60 cells
• Positive IHC detected in: human lymphoma tissue, mouse spleen tissue; Note: suggested antigen retrieval with TE buffer pH 9.0; (*) Alternatively, antigen retrieval may be performed with citrate buffer pH 6.0
• Positive IF/ICC detected in: MCF-7 cells, Jurkat cells

Recommended dilution

• Western Blot (WB): WB : 1:500-1:2000
• Immunohistochemistry (IHC): IHC : 1:50-1:500
• Immunofluorescence (IF)/ICC: IF/ICC : 1:200-1:800

It is recommended that this reagent should be titrated in each testing system to obtain optimal results.

Sample-dependent, Check data in validation data gallery.

Published Applications

• KD/KO: See 1 publications below
• WB: See 11 publications below
• IHC: See 28 publications below
• IF: See 13 publications below

Product Information

13588-1-AP targets Granzyme B in WB, IHC, IF/ICC, ELISA applications and shows reactivity with human, mouse samples.

• Tested Reactivity: human, mouse
• Cited Reactivity: human, mouse, rat
• Host / Isotype: Rabbit / IgG
• Class: Polyclonal
• Type: Antibody
• Immunogen:

  CatNo: Ag3883

  Product name: Recombinant human GZMB protein

  Source: e coli.-derived, PGEX-4T

  Tag: GST

  Domain: 1-247 aa of BC030195

  Sequence: MQPILLLLAFLLLPRADAGEIIGGHEAKPHSRPYMAYLMIWDQKSLKRCGGFLIQDDFVLTAAHCWGSSINVTLGAHNIKEQEPTQQFIPVKRPIPHPAYNPKNFSNDIMLLQLERKAKRTRAVQPLRLPSNKAQVKPGQTCSVAGWGQTAPLGKHSHTLQEVKMTVQEDRKCESDLRHYYDSTIELCVGDPEIKKTSFKGDSGGPLVCNKVAQGIVSYGRNNGMPPRACTKVSSFVHWIKKTMKRH

• Full Name: granzyme B (granzyme 2, cytotoxic T-lymphocyte-associated serine esterase 1)
• Calculated Molecular Weight: 247 aa, 28 kDa
• Observed Molecular Weight: 33 kDa
• GenBank Accession Number: BC030195
• Gene Symbol: Granzyme B
• Gene ID (NCBI): 3002
• RRID: AB_2114429
• Conjugate: Unconjugated
• Form: Liquid
• Purification Method: Antigen affinity purification
• UNIPROT ID: P10144
• Storage Buffer: PBS with 0.02% sodium azide and 50% glycerol, pH 7.3.
• Storage Conditions: Store at -20°C. Stable for one year after shipment. Aliquoting is unnecessary for -20^oC storage. 20ul sizes contain 0.1% BSA.

Background Information

GZMB(Granzyme B) is also named as CGL1, CSPB, CTLA1, GRB and belongs to the Granzyme subfamily. This enzyme is necessary for target cell lysis in cell-mediated immune responses. The cytotoxic lymphocyte protease granzyme B (GzmB) can promote apoptosis through direct processing and activation of members of the caspase family. GzmB can also cleave the BH3-only protein, BID, to promote caspase-independent mitochondrial permeabilization (PMID:17283187). GzmB induces laminB degradation in isolated nuclei less efficiently than GzmA (PMID:11331782). This full length protein has 2 glycosylation sites and a signal peptide. Unglycosylated human granzyme B is 26 kDa and high mannose glycosylated is 32 kDa and only 32kDa or smaller forms of granzyme B are accumulated within nuclei (PMID:8626751). GzmB also forms dimers.

Publications

• Human
• Mouse
• Rat
• Monkey
• Pig

Species	Application	Title
human	IHC	J Am Acad Dermatol; Generalized bullous fixed drug eruption is distinct from Stevens-Johnson syndrome/toxic epidermal necrolysis by immunohistopathological features.; Authors - Yung-Tsu Cho
mouse	IHC	Biomaterials; In situ subcutaneously injectable thermosensitive PEG-PLGA diblock and PLGA-PEG-PLGA triblock copolymer composite as sustained delivery of bispecific anti-CD3 scFv T-cell/anti-EGFR Fab Engager (BiTEE).; Authors - Pu-Sheng Wei
mouse	IHC	J Nanobiotechnology; Oxygen-delivery nanoparticles enhanced immunotherapy efficacy monitored by granzyme B PET imaging in malignant tumors; Authors - Xingyi Wang
mouse	IHC	Cancer Immunol Res; Peptide Blocking of PD-1/PD-L1 Interaction for Cancer Immunotherapy.; Authors - Chunlin Li
human	IHC	Oncogene; B7-H4 is increased in lung adenocarcinoma harboring EGFR-activating mutations and contributes to immunosuppression.; Authors - Youwei Lu
mouse	IHC	Clin Transl Med; c-Myb facilitates immune escape of esophageal adenocarcinoma cells through the miR-145-5p/SPOP/PD-L1 axis.; Authors - Lan Zhang
