CoraLite®488-conjugated MAP2 Polyclonal antibody

MAP2 Polyclonal Antibody for IF

Host / Isotype

Rabbit / IgG


human, mouse, rat




CoraLite®488 Fluorescent Dye

Cat no : CL488-17490


DKFZp686I2148, MAP 2, MAP2, MAP2A, MAP2B, MAP2C

Tested Applications

Positive IF detected inrat brain tissue
Planning an IHC experiment? We recommend our IHCeasy MAP2 Ready-To-Use IHC Kit. MAP2 primary antibody included.
For other applications, we recommend the unconjugated version of this antibody, 17490-1-AP

Recommended dilution

Immunofluorescence (IF)IF : 1:50-1:500
Sample-dependent, check data in validation data gallery

Product Information

CL488-17490 targets MAP2 in IF applications and shows reactivity with human, mouse, rat samples.

Tested Reactivity human, mouse, rat
Host / Isotype Rabbit / IgG
Class Polyclonal
Type Antibody
Immunogen MAP2 fusion protein Ag11580
Full Name microtubule-associated protein 2
Calculated molecular weight 200 kDa
Observed molecular weight
GenBank accession numberBC038857
Gene symbol MAP2
Gene ID (NCBI) 4133
Conjugate CoraLite®488 Fluorescent Dye
Excitation/Emission maxima wavelengths488 nm/515 nm
Form Liquid
Purification Method Antigen affinity purification
Storage Buffer PBS with 50% Glycerol, 0.05% Proclin300, 0.5% BSA, pH 7.3.
Storage ConditionsStore at -20°C. Avoid exposure to light. Aliquoting is unnecessary for -20oC storage.

Background Information

Microtubule-associated protein 2 (MAP2) is a tubulin binding protein regulating the spacing and stability of microtubules and contributing to elongation of dendrites.

What is the molecular weight of MAP2? Is MAP2 post-translationally modified?

MAP2 has multiple isoforms that arise from alternative splicing (PMID: 3121794, 7854050, and 10383434). They are classified into two groups - MAP2A and MAP2B, which are known as high molecular weight (HMW) isoforms, run as ~280 kDa species, while low molecular weight (LMW) isoforms MAP2C and MAP2D are around ~70 kDa. MAP2 proteins are heavily phosphorylated, which contributes to a large discrepancy between their predicted and observed molecular weight in SDS-PAGE (220 vs 280 kDa for HMW forms).

What is the tissue expression pattern of MAP2? What is the subcellular localization of MAP2?

MAP2 isoforms differ in their tissue and developmental expression pattern (PMID: 2469170 and 3898077). In the brain, MAP2B is widely expressed during and post development, MAP2A is expressed postnatally, while MAP2C is present only in the early development except of present in photosensitive cells of the adult retina and in the olfactory system. MAP proteins are highly expressed in the CNS found in cell bodies and dendrites of neurons, in dorsal root ganglion, reactive glia, and in the testis (PMID: 9588626). In neurons, MAP2 proteins are found in the cell body and dendrites, where they associate with microtubules, while they can also be present in the nuclei of testicular cells.

Can MAP2 be used as a neuronal marker?

MAP2 proteins are abundantly expressed in neurons. MAP2 is frequently used as a dendritic marker because it is present in the cell body and dendrites of neurons but absent in axons (PMID: 28413822).


Product Specific Protocols
IF protocol for CL488 MAP2 antibody CL488-17490Download protocol
Standard Protocols
Click here to view our Standard Protocols
