Biotin-conjugated PD-L1/CD274 (C-terminal) Polyclonal antibody

PD-L1/CD274 (C-terminal) Polyclonal Antibody for IHC

Host / Isotype

Rabbit / IgG

Reactivity

Human, mouse, rat

Applications

IHC

Conjugate

Biotin

Cat no : Biotin-28076

Synonyms

B7 H, B7 H1, B7 homolog 1, B7H1, CD274, CD274 molecule, PD L1, PDCD1 ligand 1, PDCD1L1, PDCD1LG1, PDL1, Programmed death ligand 1



Tested Applications

Positive IHC detected inhuman tonsillitis tissue, human placenta tissue
Note: suggested antigen retrieval with TE buffer pH 9.0; (*) Alternatively, antigen retrieval may be performed with citrate buffer pH 6.0

Recommended dilution

ApplicationDilution
Immunohistochemistry (IHC)IHC : 1:50-1:500
It is recommended that this reagent should be titrated in each testing system to obtain optimal results.
Sample-dependent, Check data in validation data gallery.

Product Information

Biotin-28076 targets PD-L1/CD274 (C-terminal) in IHC applications and shows reactivity with Human, mouse, rat samples.

Tested Reactivity Human, mouse, rat
Host / Isotype Rabbit / IgG
Class Polyclonal
Type Antibody
Immunogen PD-L1/CD274 (C-terminal) fusion protein Ag27557
Full Name CD274 molecule
Calculated Molecular Weight 290 aa, 33 kDa
Observed Molecular Weight 45-50 kDa
GenBank Accession NumberBC074984
Gene Symbol CD274
Gene ID (NCBI) 29126
RRIDAB_2918943
Conjugate Biotin
Form Liquid
Purification MethodAntigen affinity purification
Storage Buffer PBS with 50% Glycerol, 0.05% Proclin300, 0.5% BSA, pH 7.3.
Storage ConditionsStore at -20°C. Avoid exposure to light. Stable for one year after shipment. Aliquoting is unnecessary for -20oC storage. 20ul sizes contain 0.1% BSA.

Background Information

PD-L1, also known as CD274 or B7H1, stands for programmed cell death ligand 1. It is a type I transmembrane protein that is thought to repress immune responses by binding to its receptor (PD1), thus inhibiting T-cell activation, proliferation, and cytokine production. It contains V-like and C-like immunoglobulin domains. PD-L1 expression is regulated by various cytokines, such as TNF-α or LPS (ISSN: 1848-7718). Increased expression of this protein in certain types of cancers, e.g., renal cell carcinoma or colon cancer, correlates with poor prognosis.

What is the molecular weight of PD-L1?

Depending on the isoform, the calculated molecular weight of the protein varies between 20 and 33 kDa (176-290 aa).

What are the isoforms of PD-L1?

According to NCBI, three different isoforms have been identified. There are significant differences in the untranslated and protein coding regions.

What is the subcellular localization and tissue specificity of PD-L1?

It is predicted to localize in the plasma membrane of various cell types, with a particularly high expression in placental trophoblast and subsets of immune cells. High levels of PD-L1 protein have also been detected in lung and colon tissues.

What is the function of PD-L1 in immune responses?

PD-L1 is critical for the induction and maintenance of immune self-tolerance during infection or inflammation in normal tissues. The interaction of PD-L1 and its receptors is responsible for preventing auto-immune phenotypes and balancing the overall immune response in situations such as pregnancy or tissue allografts. The interaction between PD-L1 and PD-1 or B7.1 starts an inhibitory signaling cascade, which results in the decreased proliferation of antigen-specific T-cells and increased survival of regulatory T-cells (PMID: 15240681).

How can PD-L1's implication in cancer be used as a drug target?

In certain tumors, high expression of PD-L1 serves as a stop-sign to inhibit the recognition of cancer cells by T-cells (PMID: 23087408). The interaction between PD-L1 and its receptors (PD1 and B7.1) is a mechanism for the tumor to evade the host immune response (PMID: 29357948). Several mAbs have been developed to target that interaction and thus prevent the inactivation of cytotoxic T-cells by the tumor (PMIDs: 23890059, 18173375).


Protocols

Product Specific Protocols
IHC protocol for Biotin PD-L1/CD274 (C-terminal) antibody Biotin-28076Download protocol
