PICALM Monoclonal antibody

•

  WB analysis using 67564-1-Ig

  Various lysates were subjected to SDS PAGE followed by western blot with 67564-1-Ig (PICALM antibody) at dilution of 1:20000 incubated at room temperature for 1.5 hours.

•

  IHC staining of human lung cancer using 67564-1-Ig

  Immunohistochemical analysis of paraffin-embedded human lung cancer tissue slide using 67564-1-Ig (PICALM antibody) at dilution of 1:200 (under 40x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IF Staining of HeLa using 67564-1-Ig

  Immunofluorescent analysis of (-20°C Ethanol) fixed HeLa cells using PICALM antibody (67564-1-Ig, Clone: 1F6G7 ) at dilution of 1:400 and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L), CL594-Phalloidin (red).

•

  IF Staining of HepG2 using 67564-1-Ig

  Immunofluorescent analysis of (-20°C Ethanol) fixed HepG2 cells using PICALM antibody (67564-1-Ig, Clone: 1F6G7 ) at dilution of 1:800 and CoraLite®488-Conjugated Goat Anti-Mouse IgG(H+L) (SA00013-1).

PICALM Monoclonal Antibody for WB, IHC, IF/ICC, ELISA

Cat No. 67564-1-Ig

Clone No.1F6G7

Host / Isotype

Mouse / IgG1

Reactivity

human, mouse, rat

Applications

WB, IHC, IF/ICC, ELISA

Synonyms

1F6G7, CALM, CLTH, LAP, Phosphatidylinositol-binding clathrin assembly protein

---

Tested Applications

• Positive WB detected in: HeLa cells, HepG2 cells, Jurkat cells, K-562 cells, HSC-T6 cells, NIH/3T3 cells
• Positive IHC detected in: human lung cancer tissue; Note: suggested antigen retrieval with TE buffer pH 9.0; (*) Alternatively, antigen retrieval may be performed with citrate buffer pH 6.0
• Positive IF/ICC detected in: HeLa cells, HepG2 cells

Recommended dilution

• Western Blot (WB): WB : 1:5000-1:50000
• Immunohistochemistry (IHC): IHC : 1:50-1:500
• Immunofluorescence (IF)/ICC: IF/ICC : 1:200-1:800

It is recommended that this reagent should be titrated in each testing system to obtain optimal results.

Sample-dependent, Check data in validation data gallery.

Product Information

67564-1-Ig targets PICALM in WB, IHC, IF/ICC, ELISA applications and shows reactivity with human, mouse, rat samples.

• Tested Reactivity: human, mouse, rat
• Host / Isotype: Mouse / IgG1
• Class: Monoclonal
• Type: Antibody
• Immunogen:

  CatNo: Ag29512

  Product name: Recombinant human PICALM protein

  Source: e coli.-derived, PET28a

  Tag: 6*His

  Domain: 1-356 aa of BC064357

  Sequence: MSGQSLTDRITAAQHSVTGSAVSKTVCKATTHEIMGPKKKHLDYLIQCTNEMNVNIPQLADSLFERTTNSSWVVVFKSLITTHHLMVYGNERFIQYLASRNTLFNLSNFLDKSGLQGYDMSTFIRRYSRYLNEKAVSYRQVAFDFTKVKRGADGVMRTMNTEKLLKTVPIIQNQMDALLDFNVNSNELTNGVINAAFMLLFKDAIRLFAAYNEGIINLLEKYFDMKKNQCKEGLDIYKKFLTRMTRISEFLKVAEQVGIDRGDIPDLSQAPSSLLDALEQHLASLEGKKIKDSTAASRATTLSNAVSSLASTGLSLTKVDEREKQAALEEEQARLKALKEQRLKELAKKPHTSLTT

• Full Name: phosphatidylinositol binding clathrin assembly protein
• Calculated Molecular Weight: 71 kDa
• Observed Molecular Weight: 60-70 kDa
• GenBank Accession Number: BC064357
• Gene Symbol: PICALM
• Gene ID (NCBI): 8301
• RRID: AB_2882778
• Conjugate: Unconjugated
• Form: Liquid
• Purification Method: Protein G purification
• UNIPROT ID: Q13492
• Storage Buffer: PBS with 0.02% sodium azide and 50% glycerol, pH 7.3.
• Storage Conditions: Store at -20°C. Stable for one year after shipment. Aliquoting is unnecessary for -20^oC storage. 20ul sizes contain 0.1% BSA.

Background Information

PICALM (Phosphatidyl Inositol Clathrin Assembly Lymphoid Myeloid protein) is a ubiquitously expressed protein that plays a role in clathrin-mediated endocytosis. PICALM also affects the internalization and trafficking of SNAREs and modulates macroautophagy. PICALM is a highly validated genetic risk factor for Alzheimer's disease (AD). The long isoform of human PICALM has 22 exons (encoding PICALML), while the short isoform lacks exon 14 (encoding PICALMS). (PMID: 33397371, PMID: 26075887, PMID: 26005850)
