Calponin Polyclonal antibody

• Featured Product
• KD/KO Validated

Calponin Polyclonal Antibody for WB, IHC, IF/ICC, IF-P, FC (Intra), IP, ELISA

Host / Isotype

Rabbit / IgG

Reactivity

human, mouse, rat and More (2)

Applications

WB, IHC, IF/ICC, IF-P, FC (Intra), IP, ELISA

Conjugate

Unconjugated

Publications

48

Reviews (2)

Cat no : 13938-1-AP

Synonyms

CNN1, CNN 1, Calponin-1, Calponin 1, Basic calponin

---

Validation Data Gallery

•

  WB analysis using 13938-1-AP

  Various lysates were subjected to SDS PAGE followed by western blot with 13938-1-AP (Calponin antibody) at dilution of 1:30000 incubated at room temperature for 1.5 hours.

•

  WB analysis of mouse heart using 13938-1-AP

  mouse heart tissue were subjected to SDS PAGE followed by western blot with 13938-1-AP (CNN1 antibody) at dilution of 1:1000 incubated at room temperature for 1.5 hours.

•

  WB analysis of mouse lung using 13938-1-AP

  mouse lung tissue were subjected to SDS PAGE followed by western blot with 13938-1-AP (CNN1 antibody) at dilution of 1:800 incubated at room temperature for 1.5 hours.

•

  IP experiment of mouse lung using 13938-1-AP

  IP result of anti-Calponin (IP:13938-1-AP, 4ug; Detection:13938-1-AP 1:1000) with mouse lung tissue lysate 2800ug.

•

  IHC staining of human heart using 13938-1-AP

  Immunohistochemical analysis of paraffin-embedded human heart using 13938-1-AP (CNN1 antibody) at dilution of 1:50 (under 40x lens).

•

  IHC staining of human heart using 13938-1-AP

  Immunohistochemical analysis of paraffin-embedded human heart using 13938-1-AP (CNN1 antibody) at dilution of 1:50 (under 10x lens).

•

  IHC staining of human appendicitis using 13938-1-AP

  Immunohistochemical analysis of paraffin-embedded human appendicitis tissue slide using 13938-1-AP (Calponin antibody) at dilution of 1:4000 (under 10x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IHC staining of human ovary tumor using 13938-1-AP

  Immunohistochemical analysis of paraffin-embedded human ovary tumor using 13938-1-AP (CNN1 antibody) at dilution of 1:100 (under 10x lens).

•

  IHC staining of human ovary tumor using 13938-1-AP

  Immunohistochemical analysis of paraffin-embedded human ovary tumor using 13938-1-AP (CNN1 antibody) at dilution of 1:100 (under 40x lens).

•

  IHC staining of human hysteromyoma using 13938-1-AP

  Immunohistochemical analysis of paraffin-embedded human hysteromyoma using 13938-1-AP (CNN1 antibody) at dilution of 1:100 (under 10x lens).

•

  IHC staining of human hysteromyoma using 13938-1-AP

  Immunohistochemical analysis of paraffin-embedded human hysteromyoma using 13938-1-AP (CNN1 antibody) at dilution of 1:100 (under 40x lens).

•

  IHC staining of human breast cancer using 13938-1-AP

  Immunohistochemical analysis of paraffin-embedded human breast cancer using 13938-1-AP (CNN1 antibody) at dilution of 1:100 (under 10x lens).

•

  IHC staining of human breast cancer using 13938-1-AP

  Immunohistochemical analysis of paraffin-embedded human breast cancer using 13938-1-AP (CNN1 antibody) at dilution of 1:100 (under 40x lens).

•

  IHC staining of human bladder using 13938-1-AP

  Immunohistochemical analysis of paraffin-embedded human bladder using 13938-1-AP (CNN1 antibody) at dilution of 1:50 (under 10x lens).

•

  IHC staining of human bladder using 13938-1-AP

  Immunohistochemical analysis of paraffin-embedded human bladder using 13938-1-AP (CNN1 antibody) at dilution of 1:50 (under 40x lens).

•

  IHC staining of human skin using 13938-1-AP

  Immunohistochemical analysis of paraffin-embedded human skin using 13938-1-AP (CNN1 antibody) at dilution of 1:50 (under 10x lens).

•

  IHC staining of human skin using 13938-1-AP

  Immunohistochemical analysis of paraffin-embedded human skin using 13938-1-AP (CNN1 antibody) at dilution of 1:50 (under 40x lens).

•

  IHC staining of human hysteromyoma using 13938-1-AP

  Immunohistochemical analysis of paraffin-embedded human hysteromyoma using 13938-1-AP (CNN1 antibody) at dilution of 1:50 (under 10x lens).

•

  IHC staining of human hysteromyoma using 13938-1-AP

  Immunohistochemical analysis of paraffin-embedded human hysteromyoma using 13938-1-AP (CNN1 antibody) at dilution of 1:50 (under 40x lens).

•

  IF Staining of mouse heart using 13938-1-AP

  Immunofluorescent analysis of (4% PFA) fixed paraffin-embedded mouse heart tissue using Calponin antibody (13938-1-AP) at dilution of 1:200 and Multi-rAb CoraLite ® Plus 488-Goat Anti-Rabbit Recombinant Secondary Antibody (H+L) (RGAR002). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).

•

  IF Staining of mouse heart using 13938-1-AP

  Immunofluorescent analysis of (4% PFA) fixed mouse heart tissue using 13938-1-AP (Calponin antibody) at dilution of 1:50 and Alexa Fluor 488-conjugated AffiniPure Goat Anti-Rabbit IgG(H+L).

•

  IF Staining of C2C12 using 13938-1-AP

  Immunofluorescent analysis of (-20°C Methanol) fixed C2C12 cells using Calponin antibody (13938-1-AP) at dilution of 1:400 and CoraLite®488-Conjugated AffiniPure Goat Anti-Rabbit IgG(H+L).

•

  IF Staining of C2C12 using 13938-1-AP

  Immunofluorescent analysis of (-20°C Methanol) fixed C2C12 cells using Calponin antibody (13938-1-AP) at dilution of 1:200 and CoraLite®488-Conjugated AffiniPure Goat Anti-Rabbit IgG(H+L).

•

  FC experiment of C2C12 using 13938-1-AP

  1X10^6 C2C12 cells were intracellularly stained with 0.4 ug Anti-Human Calponin (13938-1-AP) and CoraLite®488-Conjugated AffiniPure Goat Anti-Rabbit IgG(H+L) at dilution 1:1000 (red), or 0.4 ug Control Antibody. Cells were fixed with 4% PFA and permeabilized with Flow Cytometry Perm Buffer (PF00011-C).

---

Tested Applications

• Positive WB detected in: mouse colon tissue, mouse heart tissue, mouse lung tissue, mouse uterus tissue
• Positive IP detected in: mouse lung tissue
• Positive IHC detected in: human appendicitis tissue, human ovary tumor tissue, human hysteromyoma tissue, human breast cancer tissue, human bladder tissue, human skin tissue, human heart tissue; Note: suggested antigen retrieval with TE buffer pH 9.0; (*) Alternatively, antigen retrieval may be performed with citrate buffer pH 6.0
• Positive IF-P detected in: mouse heart tissue
• Positive IF/ICC detected in: C2C12 cells
• Positive FC (Intra) detected in: C2C12 cells

Recommended dilution

• Western Blot (WB): WB : 1:5000-1:50000
• Immunoprecipitation (IP): IP : 0.5-4.0 ug for 1.0-3.0 mg of total protein lysate
• Immunohistochemistry (IHC): IHC : 1:2000-1:8000
• Immunofluorescence (IF)-P: IF-P : 1:50-1:500
• Immunofluorescence (IF)/ICC: IF/ICC : 1:200-1:800
• Flow Cytometry (FC) (INTRA): FC (INTRA) : 0.40 ug per 10^6 cells in a 100 µl suspension

It is recommended that this reagent should be titrated in each testing system to obtain optimal results.

Sample-dependent, Check data in validation data gallery.

Published Applications

• KD/KO: See 1 publications below
• WB: See 32 publications below
• IHC: See 5 publications below
• IF: See 13 publications below

Product Information

13938-1-AP targets Calponin in WB, IHC, IF/ICC, IF-P, FC (Intra), IP, ELISA applications and shows reactivity with human, mouse, rat samples.

• Tested Reactivity: human, mouse, rat
• Cited Reactivity: human, mouse, rat, pig, bovine
• Host / Isotype: Rabbit / IgG
• Class: Polyclonal
• Type: Antibody
• Immunogen: Calponin fusion protein Ag4989
• Full Name: calponin 1, basic, smooth muscle
• Calculated Molecular Weight: 33 kDa
• Observed Molecular Weight: 35 kDa
• GenBank Accession Number: BC022015
• Gene Symbol: Calponin
• Gene ID (NCBI): 1264
• RRID: AB_2082010
• Conjugate: Unconjugated
• Form: Liquid
• Purification Method: Antigen affinity purification
• Storage Buffer: PBS with 0.02% sodium azide and 50% glycerol pH 7.3.
• Storage Conditions: Store at -20°C. Stable for one year after shipment. Aliquoting is unnecessary for -20^oC storage. 20ul sizes contain 0.1% BSA.

Background Information

Calponin is a family of actin filament-associated proteins which regulate smooth muscle cell contraction. Three isoforms of calponin exist: calponin h1 (CNN1) , calponin h2 (CNN2) and calponin 3 (CNN3). CNN1 is a basic 34-kD protein specifically expressed in smooth muscle and a marker of smooth muscle cell differentiation. This antibody raised against the full-length of human CNN1 may cross-react with CNN2 and CNN3.

Publications

Species	Application	Title
mouse	WB	J Clin Invest; Circular RNA circEsyt2 regulates vascular smooth muscle cell remodeling via splicing regulation.; Authors - Xue Gong
rat	IF	Acta Biomater; Hybrid electrospun rapamycin-loaded small-diameter decellularized vascular grafts effectively inhibit intimal hyperplasia.; Authors - Yang Yang
mouse	WB	Theranostics; Salvia miltiorrhiza-derived miRNAs suppress vascular remodeling through regulating OTUD7B/KLF4/NMHC IIA axis.; Authors - Gao-Shan Yang
rat	WB	Phytomedicine; Betulinaldehyde inhibits vascular remodeling by regulating the microenvironment through the PLCγ1/Ca2+/MMP9 pathway; Authors - Yangxia Fu
mouse	WB	Arterioscler Thromb Vasc Biol; CRISPR-Cas9 genome editing of a single regulatory element nearly abolishes target gene expression in mice--brief report.; Authors - Yu Han
human	WB	Genomics; Identification of transfer RNA-derived fragments and their potential roles in aortic dissection.; Authors - Xiuxiu Fu

Reviews

The reviews below have been submitted by verified Proteintech customers who received an incentive for providing their feedback.

---

FH

Yajing (Verified Customer) (11-12-2019)

The antibody works well. Can be reused when stored at 4 degrees.

• Applications: Western Blot,
• Primary Antibody Dilution: 1:1000
• Cell Tissue Type: HPASMC

Calponin Antibody Western Blot, validation (1:1000 dilution) in HPASMC (Cat no:13938-1-AP)

FH

Ying (Verified Customer) (08-19-2019)

very good antibody

• Applications: Western Blot,
• Cell Tissue Type: mouse primary cardiomyocytes
