CoraLite®594-conjugated PKM2-specific Monoclonal antibody

PKM2-specific Monoclonal Antibody for IF

Host / Isotype

Mouse / IgG1

Reactivity

human, mouse, rat

Applications

IF

Conjugate

CoraLite®594 Fluorescent Dye

CloneNo.

1C11C7

Cat no : CL594-60268

Synonyms

CTHBP, OIP 3, OIP3, Opa interacting protein 3, p58, PK2, PK3, PKM, PKM1, PKM2, PKM2 pyruvate kinase, muscle, Pyruvate kinase 2/3, Pyruvate kinase isozymes M1/M2, Pyruvate kinase muscle isozyme, TCB, THBP1, Tumor M2 PK



Tested Applications

Positive IF detected inHepG2 cells
For other applications, we recommend the unconjugated version of this antibody, 60268-1-Ig

Recommended dilution

ApplicationDilution
Immunofluorescence (IF)IF : 1:300-1:1200
Sample-dependent, check data in validation data gallery

Product Information

CL594-60268 targets PKM2-specific in IF applications and shows reactivity with human, mouse, rat samples.

Tested Reactivity human, mouse, rat
Host / Isotype Mouse / IgG1
Class Monoclonal
Type Antibody
Immunogen Peptide
Full Name PKM pyruvate kinase, muscle
Calculated molecular weight 58 kDa
Observed molecular weight 58 kDa
GenBank accession numberNM_002654
Gene symbol PKM
Gene ID (NCBI) 5315
Conjugate CoraLite®594 Fluorescent Dye
Excitation/Emission maxima wavelengths593 nm/614 nm
Form Liquid
Purification Method Protein G purification
Storage Buffer PBS with 50% Glycerol, 0.05% Proclin300, 0.5% BSA, pH 7.3.
Storage ConditionsStore at -20°C. Avoid exposure to light. Stable for one year after shipment. Aliquoting is unnecessary for -20oC storage.

Background Information

PKM, also named as OIP3, PK2, PK3, PKM, p58, THBP1, CTHBP and Tumor M2-PK, belongs to the pyruvate kinase family. It is glycolytic enzyme that catalyzes the transfer of a phosphoryl group from phosphoenolpyruvate (PEP) to ADP, generating ATP. It stimulates POU5F1-mediated transcriptional activation. PKM plays a general role in caspase independent cell death of tumor cells. PKM has 2 isoforms named as PKM1/M2. The activity of the M2 isoform can be inhibited by tyrosine kinase signalling in tumourcells. The primary pyruvate kinase isoform before tumour development is PK-M1; however, the primary isoform from four independent tumours is PK-M2 (PMID:18337823). The immunogen of this antibody is M2 isoform and this antibody is specific to PKM2 isoform.

Protocols

Product Specific Protocols
IF protocol for CL594 PKM2-specific antibody CL594-60268Download protocol
Standard Protocols
Click here to view our Standard Protocols
