Various lysates were subjected to SDS PAGE followed by western blot with 67665-1-Ig (SNX5 antibody) at dilution of 1:10000 incubated at room temperature for 1.5 hours.
Various lysates were subjected to SDS PAGE followed by western blot with 67665-1-Ig (SNX5 antibody) at dilution of 1:10000 incubated at room temperature for 1.5 hours.
IHC staining of human liver cancer using 67665-1-Ig
Immunohistochemical analysis of paraffin-embedded human liver cancer tissue slide using 67665-1-Ig (SNX5 antibody) at dilution of 1:600 (under 10x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).
Immunohistochemical analysis of paraffin-embedded human liver cancer tissue slide using 67665-1-Ig (SNX5 antibody) at dilution of 1:600 (under 10x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).
IHC staining of human liver cancer using 67665-1-Ig
Immunohistochemical analysis of paraffin-embedded human liver cancer tissue slide using 67665-1-Ig (SNX5 antibody) at dilution of 1:600 (under 40x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).
Immunohistochemical analysis of paraffin-embedded human liver cancer tissue slide using 67665-1-Ig (SNX5 antibody) at dilution of 1:600 (under 40x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).
IF Staining of HeLa using 67665-1-Ig
Immunofluorescent analysis of (4% PFA) fixed HeLa cells using 67665-1-Ig (SNX5 antibody), at dilution of 1:200 and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L). F-actin was stained using CoraLite®594-phalloidin (red) and DNA was stained by DAPI (blue).
Immunofluorescent analysis of (4% PFA) fixed HeLa cells using 67665-1-Ig (SNX5 antibody), at dilution of 1:200 and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L). F-actin was stained using CoraLite®594-phalloidin (red) and DNA was stained by DAPI (blue).
FC experiment of HeLa using 67665-1-Ig
1X10^6 HeLa cells were intracellularly stained with 0.4 ug Anti-Human SNX5 (67665-1-Ig, Clone:2F8A4) and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L) at dilution 1:1000 (red), or 0.4 ug Mouse IgG2a Isotype Control (66360-2-Ig, Clone: K11A1B2A2) (blue). Cells were fixed with 4% PFA and permeabilized with Flow Cytometry Perm Buffer (PF00011-C).
1X10^6 HeLa cells were intracellularly stained with 0.4 ug Anti-Human SNX5 (67665-1-Ig, Clone:2F8A4) and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L) at dilution 1:1000 (red), or 0.4 ug Mouse IgG2a Isotype Control (66360-2-Ig, Clone: K11A1B2A2) (blue). Cells were fixed with 4% PFA and permeabilized with Flow Cytometry Perm Buffer (PF00011-C).
The Proteintech guarantee covers Proteintech antibodies in any species and any application, including those not listed on the datasheet. If the antibody doesn’t perform, you can receive a hassle-free refund or credit note.
human liver cancer tissue Note: suggested antigen retrieval with TE buffer pH 9.0; (*) Alternatively, antigen retrieval may be performed with citrate buffer pH 6.0
Positive IF/ICC detected in
HeLa cells
Positive FC (Intra) detected in
HeLa cells
Recommended dilution
Application
Dilution
Western Blot (WB)
WB : 1:5000-1:50000
Immunohistochemistry (IHC)
IHC : 1:300-1:1200
Immunofluorescence (IF)/ICC
IF/ICC : 1:50-1:500
Flow Cytometry (FC) (INTRA)
FC (INTRA) : 0.40 ug per 10^6 cells in a 100 µl suspension
It is recommended that this reagent should be titrated in each testing system to obtain optimal results.
Sample-dependent, Check data in validation data gallery.
Product Information
67665-1-Ig targets SNX5 in WB, IHC, IF/ICC, FC (Intra), ELISA applications and shows reactivity with human, mouse, rat samples.
PBS with 0.02% sodium azide and 50% glycerol, pH 7.3.
Storage Conditions
Store at -20°C. Stable for one year after shipment. Aliquoting is unnecessary for -20oC storage. 20ul sizes contain 0.1% BSA.
Background Information
Sorting nexins are a diverse group of cytoplasmic and membrane-associated proteins that are classified by the presence of a phospholipid-binding motif-the PX domain (PMID:12461558). They are involved in endocytosis and protein trafficking. SNX5 (Sorting nexin-5) was originally identified as a putative FANCA-binding protein (PMID: 10600472). SNX5 has a phox homology (PX) domain in the N-terminus. It is involved in several stages of intracellular trafficking. SNX5 is a component of the mammalian retromer complex, which is involved in recycling proteins from endosomes to the trans-Golgi network or plasma membrane (PMID: 17148574; 26199408).
Various lysates were subjected to SDS PAGE followed by western blot with 67665-1-Ig (SNX5 antibody) at dilution of 1:10000 incubated at room temperature for 1.5 hours.
IHC Figures
IHC staining of human liver cancer using 67665-1-Ig
Immunohistochemical analysis of paraffin-embedded human liver cancer tissue slide using 67665-1-Ig (SNX5 antibody) at dilution of 1:600 (under 10x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).
IHC staining of human liver cancer using 67665-1-Ig
Immunohistochemical analysis of paraffin-embedded human liver cancer tissue slide using 67665-1-Ig (SNX5 antibody) at dilution of 1:600 (under 40x lens). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0).
IF/ICC Figures
IF Staining of HeLa using 67665-1-Ig
Immunofluorescent analysis of (4% PFA) fixed HeLa cells using 67665-1-Ig (SNX5 antibody), at dilution of 1:200 and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L). F-actin was stained using CoraLite®594-phalloidin (red) and DNA was stained by DAPI (blue).
FC (INTRA) Figures
FC experiment of HeLa using 67665-1-Ig
1X10^6 HeLa cells were intracellularly stained with 0.4 ug Anti-Human SNX5 (67665-1-Ig, Clone:2F8A4) and CoraLite®488-Conjugated AffiniPure Goat Anti-Mouse IgG(H+L) at dilution 1:1000 (red), or 0.4 ug Mouse IgG2a Isotype Control (66360-2-Ig, Clone: K11A1B2A2) (blue). Cells were fixed with 4% PFA and permeabilized with Flow Cytometry Perm Buffer (PF00011-C).
The species listed in Tested Reactivity are in-house verified and applicable species. For unlisted species, please refer to the homology analysis of the immunogen sequence and related species. For rabbit polyclonal antibodies, homology >70% is recommended. For mouse monoclonal antibodies and rabbit recombinant antibodies, homology >90% is recommended. Generally, the higher the homology, the greater the applicability. However, there will be certain differences in protein expression in different species, tissues or cells. Therefore, the homology analysis results are for reference only and do not serve as a guarantee.
At Proteintech, we pride ourselves on our antibody quality, customer service and transparency. As such, we are comparing our antibodies with other vendors, enabling easy identification and comparisons of key data to help you choose the suitable antibody for your needs.
We have selected the top cited antibodies from these vendors for you to compare.
Proteintech
SNX5 Monoclonal antibody
Catalog Number
67665-1-Ig
Citations
-
Dilutions
WB : 1:5000-1:50000 IHC : 1:300-1:1200 IF/ICC : 1:50-1:500 FC (INTRA) : 0.40 ug per 10^6 cells in a 100 µl suspension
Applications
WB, IHC, IF/ICC, FC (Intra), ELISA
Reactivity
human, mouse, rat
Product Guarantee
Covers any species including not listed on datasheet
Covers any applications including not listed on datasheet
