CoraLite®594-conjugated TMEM173/STING Polyclonal antibody

TMEM173/STING Polyclonal Antibody for IF/ICC, IF-P, FC (Intra)

Host / Isotype

Rabbit / IgG

Reactivity

human and More (2)

Applications

WB, IF/ICC, IF-P, FC (Intra)

STING, Endoplasmic reticulum interferon stimulator, ERIS, MITA, MPYS

Formulation:  PBS, Proclin300, BSA, Glycerol
PBS, Proclin300, BSA, Glycerol
Size/Concentration:
SKU:

-/ -

Freight/Packing: -

Quantity

Please visit your regions distributor:

Able AI
Able AI
What's the best dilution for TMEM173/STING in ?

Tested Applications

Positive IF-P detected inhuman tonsillitis tissue
Positive IF/ICC detected inHT-29 cells, human tonsillitis tissue, HepG2 cells
Positive FC (Intra) detected inTHP-1 cells

Recommended dilution

ApplicationDilution
Immunofluorescence (IF)-PIF-P : 1:50-1:500
Immunofluorescence (IF)/ICCIF/ICC : 1:50-1:500
Flow Cytometry (FC) (INTRA)FC (INTRA) : 0.80 ug per 10^6 cells in a 100 ul suspension
It is recommended that this reagent should be titrated in each testing system to obtain optimal results.
Sample-dependent, Check data in validation data gallery.

Product Information

CL594-19851 targets TMEM173/STING in WB, IF/ICC, IF-P, FC (Intra) applications and shows reactivity with human samples.

Tested Reactivity human
Cited Reactivitymouse, rat
Host / Isotype Rabbit / IgG
Class Polyclonal
Type Antibody
Immunogen

CatNo: Ag13921

Product name: Recombinant human TMEM173 protein

Source: e coli.-derived, PGEX-4T

Tag: GST

Domain: 174-379 aa of BC047779

Sequence: ELQARIRTYNQHYNNLLRGAVSQRLYILLPLDCGVPDNLSMADPNIRFLDKLPQQTGDHAGIKDRVYSNSIYELLENGQRAGTCVLEYATPLQTLFAMSQYSQAGFSREDRLEQAKLFCRTLEDILADAPESQNNCRLIAYQEPADDSSFSLSQEVLRHLRQEEKEEVTVGSLKTSAVPSTSTMSQEPELLISGMEKPLPLRTDFS

Predict reactive species
Full Name transmembrane protein 173
Calculated Molecular Weight 379 aa, 42 kDa
Observed Molecular Weight 35-40 kDa, 80 kDa
GenBank Accession NumberBC047779
Gene Symbol STING
Gene ID (NCBI) 340061
RRIDAB_2919854
Conjugate CoraLite®594 Fluorescent Dye
Excitation/Emission Maxima Wavelengths588 nm / 604 nm
Excitation LaserYellow-Green Laser (561 nm)
FormLiquid
Purification MethodAntigen affinity purification
UNIPROT IDQ86WV6
Storage Buffer PBS with 50% glycerol, 0.05% Proclin300, 0.5% BSA, pH 7.3.
Storage ConditionsStore at -20°C. Avoid exposure to light. Stable for one year after shipment. Aliquoting is unnecessary for -20oC storage.

Background Information

Stimulator of interferon genes (STING, also known as ERIS, MITA and MPYS, and encoded by TMEM173) is a transmembrane adaptor protein that facilitates innate immune signaling (PMID: 18724357). STING is widely expressed in various cell types such as endothelial cells, epithelial cells, T cells, macrophages, and dendritic cells (PMID: 26603901). It is predominantly located in the endoplasmic reticulum (ER). STING functions as a sensor of cytosolic DNA and promotes the production of type I interferons and pro-inflammatory cytokines.

Protocols

Product Specific Protocols
FC protocol for CL594 TMEM173/STING antibody CL594-19851Download protocol
IF protocol for CL594 TMEM173/STING antibody CL594-19851Download protocol
Standard Protocols
Click here to view our Standard Protocols

Publications

What published studies show

The CoraLite®594-conjugated TMEM173/STING Polyclonal antibody (CL594-19851) has been cited in 3 publications. The citations appear in ACS Nano (2025), Journal of Neuroinflammation (2023), and Molecular Pharmaceutics (2024). The research fields associated with these citations are neuroprotection and ischemia–reperfusion brain injury, retinal degeneration and the cGAS/STING pathway in light damage, and STING-targeted PET imaging for myocarditis, spanning applications in WB and IF.

SpeciesApplicationTitle
ratWB

ACS Nano

Unlocking Neuroprotection: Simultaneous Suppression of Mitochondrial Energetic Collapse and Oxidative-Inflammatory Vortex for Ischemia-Reperfusion Brain Injury.

Authors - Shuya Wang
mouseIF

J Neuroinflammation

The BET PROTAC inhibitor dBET6 protects against retinal degeneration and inhibits the cGAS-STING in response to light damage

Authors - Xingfei Zhu
mouse

Mol Pharm

STING-Targeted PET Imaging for Specific Detection and Therapeutic Monitoring of Myocarditis

Authors - Zhou Ye
