Product Information
The ChromoTek GFP-Trap® Magnetic Agarose are affinity beads for IP of GFP-fusion proteins. It comprises a GFP Nanobody/ VHH coupled to magnetic agarose beads.
| Description | Immunoprecipitation of GFP-fusion proteins and their interacting factors with anti-GFP Nanobody conjugated to magnetic agarose beads.
• Fast, reliable & efficient one-step immunoprecipitation • Ready-to-use • No heavy & light antibody chains • Stable under harsh washing conditions • Suitable for downstream mass spec analysis • Works in samples from: mammals, plants, bacteria, yeast, insects etc. |
| Applications | IP, CoIP, ChIP, RIP |
| Specificity/Target | AcGFP, Clover, eGFP, Emerald, GFP, GFP5, GFP Envy, GFP S65T, mGFP, mPhluorin, PA-GFP, Superfolder GFP, TagGFP, TagGFP2, monomeric eGFP A206K, CFP, YFP, Citrine, eCitrine, eYFP, Venus, Ypet, BFP For the complete list, please click here: Fluorescent protein specificity table |
| Binding capacity | 15-20 μg of recombinant GFP per 25 μL bead slurry |
| Conjugate | Magnetic agarose beads; bead size: ~40 µm (cross-linked 6 % magnetic agarose beads) |
| Elution buffer | SDS sample buffer 0.2 M glycine pH 2.5 |
| Wash buffer compatibility | 1 mM DTT, 3 M Guanidinium•HCl, 8 M Urea, 2 M NaCl, 2 % Nonidet P40 Substitute, 1 % SDS, 1 % Triton X-100 |
| Type | Nanobody |
| Class | Recombinant |
| Host | Alpaca |
| Affinity (KD) | Dissociation constant KD of 1 pM |
| Compatibility with mass spectrometry | The GFP-Trap® is optimized for on-bead digestion. For the application note, please click here: On-bead digest protocol for mass spectrometry |
| RRID | AB_2631358 |
| Storage Buffer | 20% ethanol |
| Storage Condition | Shipped at ambient temperature. Upon receipt store at 4°C. Stable for one year. Do not freeze! |
| Size | 25ul/reactions (eg：20rxns=500ul slurry) |
Documentation
| SDS |
|---|
| gtma_SDS_GFP-Trap® Magnetic Agarose (EN) |
| Protocol |
|---|
| GFP-Trap 磁性琼脂糖珠操作说明（中文） |
| Datasheet |
|---|
| GFP-Trap® Magnetic Agarose Datasheet |
| Trouble shooting |
|---|
| Troubleshooting guide immunoprecipitation (IP) |
| GFP-Trap Specificity |
|---|
| Fluorescent protein specificity table |
Publications
| Application | Title |
|---|---|
Cell Chromatin remodeling of histone H3 variants by DDM1 underlies epigenetic inheritance of DNA methylation | |
Reviews
The reviews below have been submitted by verified Proteintech customers who received an incentive for providing their feedback.
FH Keerthi (Verified Customer) (10-06-2025) | I have been using the GFP trap magnetic agarose beads for pull down experiments of GFP tagged protein of interest. I am highly satisfied with the quality of the product and also the results, considering the fact that the samples I use are known to be low yielding cells. This was one of the major experiments I did in my PhD and I am so happy with the results. Additionally, the whole Proteintech team was extremely helpful and always available for any questions I had. I have already recommended the products to some colleagues!
|
FH Antonio (Verified Customer) (10-03-2025) | GFP-Trap magnetic beads are fast and allow us to immunocapture and purify our protein at a glance, we can process it for further analysis. It allows to have great reproducibility between replicates.
|
FH Morgane (Verified Customer) (09-30-2025) | Works very well on a lower number of cells. Clean Elution. Quick and easy to use !
 |
FH Monifa (Verified Customer) (09-19-2025) | GFP-tagged sample bound to beads slurry according to the binding capacity advertised. I eluted in 2x SDS sample buffer and saw specific elution with GFP-tagged samples. It was great to not have to deal with heavy or light chain leakage into the elution.
|
FH Precious (Verified Customer) (08-24-2025) | The GFP-trap nanobody worked really well for our GFP pull down experiments coupled to UV-RNA-immunoprecipitation.
|
FH Maurizio (Verified Customer) (04-30-2025) | Excellent reagent. The pull-down efficiency of the GFP-Trap system is way higher than the one obtained with standard anti-GFP antibodies.
 |
FH Timo (Verified Customer) (01-30-2025) | CoIP resulted in a very clean result and the technical support was excellent. Will 100% recommend!
|
FH Karel (Verified Customer) (11-20-2024) | We achieved very nice recovery of protein of interest.
|
FH Haifei (Verified Customer) (09-13-2024) | Easily followed protocol. Clean results.
|
FH Alen (Verified Customer) (08-20-2024) | Great and convenient product
|
FH Margaux (Verified Customer) (06-11-2024) | I used GFP-TRAP to isolate GFP-tagged proteins. It was very efficient and it's a real advantage not to have to deal with heavy and light antibody chains.
|
FH Titouan (Verified Customer) (06-11-2024) | Very efficient pull-down of GFP-tagged protein from cell lysates (293T, Hela...) and very easy to use
|
FH Mona (Verified Customer) (08-03-2023) | I purified GF tagged protein and efficiency was almost 100%
|
FH Rhys (Verified Customer) (11-08-2022) | Used for IP of a eGFP tagged construct, easy to use and excellent efficiency.
|
FH Peter (Verified Customer) (10-24-2022) | Best system I have used for GFP IPs
|
FH Amy (Verified Customer) (09-02-2022) | Efficient pull down of GFP-tagged protein from HEK293T cell lysates.
|
FH Rich (Verified Customer) (07-26-2022) |
 |
FH James (Verified Customer) (06-16-2022) | Overexpressed GFP in HEK293T cells - efficient pulldown with GFP beads.
|
